Mine Water Containing Specific Pollutants

Process Flow Diagram

Technical Reserve

Develop a customized technology cluster of "specialized pretreatment - intelligent interlocking - resource recovery" to tackle the challenges of removing complex pollutants such as cyanide, mercury, and oil, achieving compliant discharge and value recovery.

1、Targeted Treatment Technology: Catalytic ozone achieves 99% cyanide degradation rate within 30 minutes; nano-sulfide reduces mercury to 0.001mg/L; electrocoagulation flotation achieves 98% oil removal rate.

2、Multi-process Coordination System: GC-MS online detection interlocks with 5-minute mode switching, adapting to pollutant concentration fluctuations of ±40%.

3、Resource Recovery Process: Waste oil recovery rate reaches 95%; precious metal adsorbents can be regenerated ≥50 times, reducing hazardous waste and material consumption.

Industrialization Advantages

Provide "one enterprise, one strategy" customized solutions, leveraging rapid adaptation capabilities and proprietary core chemical technologies to meet stringent environmental standards.

1、Modular Customization: 45-day delivery project with single-unit treatment capacity of 50-1,000 m³/day, flexibly addressing multi-pollutant scenarios.

2、In-house Core Technologies: Self-synthesized cyanide-breaking catalysts and chelating agents reduce costs by 40%, with air flotation energy consumption ≤0.3kW・h/m³.

3、Full-chain Compliance Assurance: Testing training + blockchain certification ensures traceable treatment processes and 100% environmental compliance rate.
